M12-C02 M12-5 male screw connector2TLA020055R1100₹822.00Straight M12-5 male connector with cable screw connection. Cable diameter range 2.5–6.5 mm. Learn More
Eva General code2TLA020046R0800₹1,685.00Eva actuator with general code for use with Adam DYN/OSSD sensors in the Eden sensor system, IP69K, yellow, 4pcs of DA 2B spacer rings are included. Learn More
Smile 12 EA Tina2TLA030050R0200₹5,608.00Emergency stop button in Smile enclosure, Tina adaptation unit to DYNlink included, Status LED in button, 1 x M12 5-pin male connector and 1 x M12 5-pin female connector. Learn More
MKey8M 24VDC, power to lock, IP672TLA050013R0132₹27,753.00Safety interlock switch, die cast housing and head, 3xM20 conduits entries, +24VDC power to lock. Delivered with standard key. Learn More
Smile 11 EA2TLA030051R0000₹6,356.00Emergency stop button in Smile enclosure, 2 x NC, Status LED in button, 1 x M12 5-pin male connector. Learn More
Smile 11 EA Tina2TLA030050R0000₹7,323.00Emergency stop button in Smile enclosure, Tina adaptation unit to DYNlink included, Status LED in button, 1 x M12 5-pin male connector. Learn More
Tina 1A Blind plug for DYNlink2TLA020054R0000Out of stockTina 1A blind plug is connected to the unused M12 connectors of the connection blocks Tina 4A or Tina 8A. M12-5 male connector. Learn More
Tina 4A Connection block 4 DYNlink M12-52TLA020054R0300Out of stockConnection block for series connection of up to 4 DYNlink devices. Four M12-5 female connectors for the devices. The information signal of each device can be wired separately. The cable used for the connection to the Tina 4A should have a diameter 7 - 12 mm. If less than a devices are connected, complete with Tina 1A blind plugs. Learn More
JSHD4H2 3-pos device panel mounting. 6x1200mm leads.2TLA020002R4500Out of stockJSHD4H2 Three-position control device for internal panel mounting. 6x1200mm leads. Learn More
M12-CANend termination resistor encoder2TLA020061R0300Out of stockM12-5 plug with Pluto safety bus termination resistor for encoders. To be used when the encoder is at one end of the Pluto safety bus. Learn More
JSHD4 Bottom part AL with JSM 53A2TLA020005R2000Out of stockBottom part with JSM 53A and cable gland Learn More
JSTD1-C Safeball 10m cable2TLA020007R3200Out of stockJSTD1-C Safeball, 1NO + 1NC, 10 m cable (4 leads). Ergonomic design with several grip possibilities and low activation force (approx. 2N) and flexible mounting options. Provides highest level of safety for use in two hand control applications when using two Safeballs in conjunction with appropriate safety relay or Pluto Safety PLC. Maximum load of 30VDC, 2A resistive, IP67 protection degree, plastic body. Learn More
C13 cable (11x0.51 + 2x0.82) shielded2TLA020057R2000Out of stockCable 11 x 0.51 mm2 + 2 x 0.82 mm2 + screen, specify length. Recommended to use with a Tina 8A. Learn More
Tina 3A Adapter 2 contacts M12-52TLA020054R0200Out of stockAdaptation of devices with 2 positively driven force-guided contacts like emergency stop buttons and key switches, to the DYNlink solution. Tina 3A is mounted directly on the device enclosure to a M20 cable entry and has a M12-5 male connector for connection to the DYNlink loop. Learn More
JSHD4H2 3-pos device panel mounting. 6x150mm leads.2TLA020002R3100Out of stockJSHD4H2 Three-position control device for internal panel mounting. 6x150mm leads. Learn More
JSHK1-B Male plug for cable2TLA020003R0900Out of stock12-pole male Cannon connector for cable mounting. Learn More
JSHD4-4-AH-A Enabling Switch2TLA019995R3100Out of stockThree-position device. Top part with LEDs and front button. Bottom part with cable gland and PCB with 10 screw connection and anti-tamper PCB. Learn More
JSHD4-2-AD Enabling Switch2TLA019995R0400Out of stockThree-position device. Top part with LEDs, front button and top button. Bottom part with M12-8 connector. Learn More
M12-C103 10 m cable M12-8 female conn.2TLA020056R4000Out of stock10 m cable 8 x 0.34 mm2 + shield with straight M12-8 female connector. Learn More
Tina 2A Adapter 2 contacts2TLA020054R0100Out of stockAdaptation of devices with 2 positively driven force-guided contacts like emergency stop buttons and key switches, to the DYNlink solution. Tina 2A is mounted directly on the device enclosure to a M20 cable entry. Learn More
INCA 1S Safety Stop2TLA030054R0300Out of stockSafety stop (black button) for panel mounting, 22.5 mm holes, 2 NC contacts, status LED in button, terminal blocks. Learn More
M12-3S M12 Y-connector2TLA020055R0600Out of stockM12-3S M12 Y-connector for series connection of DYNlink devices with the StatusBus function. One M12-5 pole female connector (#2) for connection of the safety device, one M12-5 male connector (#1) for connection of +24VDC, 0V, the incoming dynamic signal and the StatusBus and one M12-5 female connector (#3) for the outgoing inverted dynamic signal towards another safety device or Vital/Pluto safety PLC. Learn More
M12-C101 10m cable M12-5 female conn.2TLA020056R1000Out of stock10 m cable 5 x 0.34 mm2 + shield with straight M12-5 female connector. Learn More
Adam OSSD-Reset M12-5 connector2TLA020051R5600Out of stockAdam safety sensor unit with OSSD signals and reset with indication. M12-5 male connector, IP69K, yellow. 4pcs of DA 1B distance plates and 4pcs of DA 2B distance rings are included. Learn More
Adam OSSD-Info M12-5 connector2TLA020051R5400Out of stockAdam safety sensor unit with OSSD signals and information output. M12-5 male connector, IP69K, yellow. 4pcs of DA 1B distance plates and 4pcs of DA 2B distance rings are included. Learn More© ABB India Ltd. | Address: 88/3-88/6, Basavanahalli Village, Kasaba Hobli, Bengaluru, Karnataka - 562123
LineStrong3D, 4NC/4NO, M20 ESTOP/LED2TLA050204R0332Out of stockEmergency stop grab wire safety switch, 4NC + 4NO, Entries from both sides of the grab wire switch, Up to 250m length, yellow die cast housing, LED status indication, Conduit entry 3xM20 Learn More
Adam DYN-Reset M12-5 connector2TLA020051R5300Out of stockAdam safety sensor unit with DYNlink signal and reset with indication. M12-5 male connector, IP69K, yellow. 4pcs of DA 1B distance plate and 4pcs of DA 2B distance rings are included. Learn More
JSHD4-4-AJ-A Enabling Switch2TLA019995R3300Out of stockThree-position device. Top part with LEDs and front button. Bottom part with cable gland and PCB with 16 screw connections and anti-tamper PCB. Learn More
JSHD4 Bottom part AH Cable Gland+PCB-102TLA020005R1700Out of stockBottom part with cable gland and PCB with 10 screw connections Learn More
